Methods to Setup DKIM for Microsoft 365

Read time: 5 minutes

Nowadays, the rise in cyber threats is really a big concern that requires efficient handling from the mail administrator. It is an ongoing battle that may get worse due to various phishing campaigns implemented by attackers. Fortunately, growth in technology introduced various new standards to be protected against such attempts.

To prevent various cyber threats, including email spoofing and phishing attacks, each organization needs to implement DKIM in Microsoft 365. As email usage and capabilities continuously grow, this protocol must configure to Microsoft 365 to ensure that the receiving mail comes from a legitimate domain. DKIM (DomainKeys Identified Mail) is one of the trios of authentication protocols (SPF, DMARC, and DKIM) where a digital signature is added to all outbound email messages. To check the legacy of the sender domain, the receiver server determines these signatures. It also includes a private key which is responsible for encrypting the header of the outgoing mail.

This protocol also transfers the sender’s emails to spam or junk folders. It generally happens when the sender domain doesn’t pass the authentication tests.

Setup DKIM for Microsoft 365

The configuring of the specific protocol to Microsoft 365 doesn’t require in the below two cases:

But if you are not involved in any of the above cases, you can configure it in Microsoft 365 through the manual approach. It includes several stages, such as creating two DKIM records, publishing them for your custom domain in DNS, and enabling signing.

Create DKIM records for Microsoft 365

Creating records of the specific protocol is quite important as it maps an alias name to the specific domain name. To create a custom domain, you must create records for pointing out the initial domain. These records look like the following:

Host name: selector1._domainkey.CompanyDomainName
Points to: selector1-CompanyDomainName-com._domainkey.TenantName.onmicrosoft.com
Host name: selector2._domainkey.CompanyDomainName
Points to: selector2-CompanyDomainName-com._domainkey.TenantName.onmicrosoft.com

If the company domain is xyz.com, you need to create below two records:

Host name: selector1._domainkey.xyz.com
Points to: selector1-company-com._domainkey.company.onmicrosoft.com
Host name: selector2._domainkey.xyz.com
Points to: selector2-company-com._domainkey.company.onmicrosoft.com

Publish DKIM records in DNS

If you create a custom domain in addition to the default domain, you must publish two records for a single custom domain. For this, you need to use the following format for these records:

Host name: selector1._domainkey
Points to address or value: selector1-._domainkey.
TTL: 3600
Host name: selector2._domainkey
Points to address or value: selector2-._domainkey.
TTL: 3600

Enable DKIM signing

After performing the above steps, now it’s time to enable signing in Microsoft 365. You can perform the same using two methods, i.e., Microsoft 365 Defender or PowerShell.

Enable DKIM signing using Microsoft 365 Defender portal

If you want to enable this signing using the Defender portal, you must follow the below steps:

If you receive error messages while enabling the signing using the Microsoft 365 Defender portal, another method is also available, i.e., PowerShell.

Enable DKIM signing using PowerShell

You can also use PowerShell to enable signing in Microsoft 365. For this, you must follow the below steps:

Confirm DKIM signing is configured properly for Microsoft 365

Conclusion

Many organizations setup this protocol for Microsoft 365 to ensure the safe delivery of mail to client/customer mailboxes. You might see that some of the incoming emails from the specific domain transfer to your spam or junk folder. Have you ever thought about which mechanism relies on this? Actually, this protocol is responsible in this particular case; it happens when the domain of the incoming mail doesn’t pass the authentication tests. You can consider it as an effective authentication method to secure Office 365 mailboxes.

Before setting this authentication protocol for Microsoft 365, it is recommended to keep a backup of your mailboxes to prevent data loss. You can use an effective tool named Kernel Office 365 Backup & Restore that is capable of backing up your private mailboxes, shared mailboxes, archive mailboxes, and Microsoft 365 groups. Hence, you need not worry as data can easily be restored if data loss happens.
